[cpp]
#include <Adafruit_NeoPixel.h>
#include <SPI.h>
#include <Ethernet.h>
#include <EEPROM.h>

#define PIN 6

// Parameter 1 = number of pixels in strip
// Parameter 2 = pin number (most are valid)
// Parameter 3 = pixel type flags, add together as needed:
// NEO_KHZ800 800 KHz bitstream (most NeoPixel products w/WS2812 LEDs)
// NEO_KHZ400 400 KHz (classic ’v1’ (not v2) FLORA pixels, WS2811 drivers)
// NEO_GRB Pixels are wired for GRB bitstream (most NeoPixel products)
// NEO_RGB Pixels are wired for RGB bitstream (v1 FLORA pixels, not v2)
Adafruit_NeoPixel strip = Adafruit_NeoPixel(40, PIN, NEO_GRB + NEO_KHZ800);

byte mac[] = {0x90, 0xA2, 0xDA, 0x0E, 0x95, 0x3F};

IPAddress ip(192,168,0,99);

// Initialize the Ethernet server library
// with the IP address and port you want to use
// (port 80 is default for HTTP):
EthernetServer server(80);

int startValue = 255;
int red = startValue;
int green = startValue;
int blue = startValue;
int interval = startValue;
int brightness = 255;
String readString = "";
String lastValue = "";
const String RED = "red";
const String GREEN = "green";
const String BLUE = "blue";
const int RED_ADDRESS = 0;
const int GREEN_ADDRESS = 1;
const int BLUE_ADDRESS = 2;

void setup() {
Serial.begin(9600);

strip.begin();
strip.show(); // Initialize all pixels to ’off’
strip.setBrightness(brightness);

int tmpRed = EEPROM.read(RED_ADDRESS);
int tmpGreen = EEPROM.read(GREEN_ADDRESS);
int tmpBlue = EEPROM.read(BLUE_ADDRESS);
if(tmpRed > 0 || tmpGreen > 0 || tmpBlue > 0){
red = tmpRed;
green = tmpGreen;
blue = tmpBlue;
colorWipe(strip.Color(red, green, blue));
}else{
colorWipe(strip.Color(red, green, blue));
}

Ethernet.begin(mac, ip);
server.begin();
Serial.print("server is at ");
Serial.println(Ethernet.localIP());
}

void loop() {
// listen for incoming clients
EthernetClient client = server.available();
if (client) {
Serial.println("new client");
// an http request ends with a blank line
boolean currentLineIsBlank = true;
while (client.connected()) {
if (client.available()) {
char c = client.read();

//read char by char HTTP request
if (readString.length() < 100) {
//store characters to string
readString += c;
}

Serial.write(c);
// if you’ve gotten to the end of the line (received a newline
// character) and the line is blank, the http request has ended,
// so you can send a reply
if (c == ’\n’ && currentLineIsBlank) {
// send a standard http response header
client.println("HTTP/1.1 200 OK");
client.println("Content-Type: application/json");
client.println("Connection: close");
client.println();
client.println(prepareHtml());
break;
}
if (c == ’\n’) {
// you’re starting a new line
currentLineIsBlank = true;
}
else if (c != ’\r’) {
// you’ve gotten a character on the current line
currentLineIsBlank = false;
}
}
}
// give the web browser time to receive the data
delay(1);
// close the connection:
client.stop();
Serial.println("client disonnected");

String queryString = getQueryString(readString);

if(getValue(queryString, RED).length() > 0)
{
red = getIntValue(getValue(queryString, RED));
EEPROM.write(RED_ADDRESS, red);
Serial.print("red:");
Serial.println(red);
}
if(getValue(queryString, GREEN).length() > 0)
{
green = getIntValue(getValue(queryString, GREEN));
EEPROM.write(GREEN_ADDRESS, green);
Serial.print("green:");
Serial.println(green);
}
if(getValue(queryString, BLUE).length() > 0)
{
blue = getIntValue(getValue(queryString, BLUE));
EEPROM.write(BLUE_ADDRESS, blue);
Serial.print("blue:");
Serial.println(blue);
}

//clearing string for next read
readString="";
queryString="";

colorWipe(strip.Color(red, green, blue));
setBrightness(brightness);
Serial.print(lastValue);
} // client
}

void setBrightness(int brightness){
strip.setBrightness(brightness);
}

String prepareHtml(){
String html = "{\"status\":\"ok\"}";
int tmpRed = EEPROM.read(RED_ADDRESS);
int tmpGreen = EEPROM.read(GREEN_ADDRESS);
int tmpBlue = EEPROM.read(BLUE_ADDRESS);
if(tmpRed > 0 || tmpGreen > 0 || tmpBlue > 0){
html = "{\"status\":\"ok\", \"rgb\":["+String(tmpRed)+","+String(tmpGreen)+","+String(tmpBlue)+"]}";
}else{
html = "{\"status\":\"ok\", \"rgb\":["+String(startValue)+","+String(startValue)+","+String(startValue)+"]}";
}
return html;
}

// Fill the dots one after the other with a color
void colorWipe(uint32_t c) {
for(uint16_t i=0; i<strip.numPixels(); i++) {
strip.setPixelColor(i, c);
strip.show();
}
}

int getIntValue(String value){
int tmpValue = value.toInt();
if(tmpValue > 255){
return 255;
}
if(tmpValue < 0){
return 0;
}

return tmpValue;
}

String getValue(String queryString, String param){

if(queryString.indexOf("?") > -1 && queryString.indexOf(param) > -1){
//Serial.print(param);Serial.println(queryString.indexOf(’?’) > -1 && queryString.indexOf(param) > -1);
int paramPos = queryString.indexOf(param) + 1 + param.length();
int AndCharPosOrLength = queryString.indexOf("&",paramPos);
if(paramPos > 0){
if(AndCharPosOrLength == -1){
AndCharPosOrLength = queryString.length();
}
return queryString.substring(paramPos, AndCharPosOrLength);
}
}
return "";
}

String getQueryString(String httpHeader){
String startString = "GET /";
String endString = " HTTP/1.1";
int startPos = httpHeader.indexOf(startString) + startString.length();
int endPos = httpHeader.indexOf(endString, startPos);

if(startPos > 0 && endPos > 0){
Serial.println(httpHeader.substring(startPos, endPos));
return httpHeader.substring(startPos, endPos);
}
return "";
}
